(80Ni20Cr) (N06003) (W.Nr.2.4869) (NCHW-1) (NCHR-1) (NiCr8020) (NiCr 80/20) (Х20Н80) (Х20Н80-Н) (Nichrome 80) (Nikrothal 80) (Resistohm 80) ( Cronix 80) (Nichrome V) (HAI-NiCr 80) (Cr20Ni80) (Ni80Cr20)
80/20 Ni Cr Wire is an alloy used at operating temperatures up to 1200°C (2200°F). Its chemical composition gives good oxidation resistance, especially under conditions of frequent switching or wide temperature fluctuations. This makes it ideal for a wide variety of applications including heating elements in domestic and industrial appliances, wire-wound resistors, through to the aerospace industry.
| Nickel-chromium, nickel, ferrochrome alloy wire with electric high temperature oxidation resistance, high strength, not soften and a series of advantages. When used in a long time, the same type and the permanent elongation is very small, which is more Cr20Ni80 alloy with excellent comprehensive properties, is to produce high-quality varieties of choice for electric components. |
| property/type |
Cr20Ni80 |
Cr30Ni70 |
Cr15Ni60 |
Cr20Ni35 |
| Main chemical composition |
Ni |
rest |
rest |
55.0-61.0 |
34.0-37.0 |
| Cr |
20.0-23.0 |
28.0-31.0 |
15.0-18.0 |
18.0-21.0 |
| Fe |
≤1.0 |
≤1.0 |
rest |
rest |
| Max working temperature°c |
1200 |
1250 |
1150 |
1100 |
| Melting temperature°c |
1400 |
1380 |
1390 |
1390 |
| Density g/cm3 |
8.4 |
8.1 |
8.2 |
7.9 |
| Resistivity Ω. 20°c |
1.09±0.05 |
1.18±0.05 |
1.11±0.05 |
1.04±0.05 |
| Elongation |
≥20 |
≥20 |
≥20 |
≥20 |
| Thermal conductivity |
60.3 |
45.2 |
45.2 |
43.8 |
